Auto Sheet Number - click this button to apply sheet numbering, in accordance with the chosen numbering scheme/method.This option can also be enabled from the Project Options - Options dialog. Automatic Sheet Numbering (Project Options) - enable this option to apply automatic numbering to the schematic sheets in the project. This allows control over the sheet designation and stores them as parameters within the respective schematic documents.Changes will be effected once the OK button is clicked. Use the Sheet Numbering For Project dialog to number and organize the schematic sheets in a project.Ī field that has been modified with respect to its value will be distinguished by the use of a blue triangle in its top-right corner. Sheet numbering is accessed by clicking Tools » Annotation » Number Schematic Sheets from the main menus to open the Sheet Numbering For Project dialog. Conceptually, it is therefore related to the general concept of design annotation. The numbering does not alter component designators but rather Schematic Sheet Designators (numbers). The special string feature ( =SheetNumber, =DocumentNumber, =SheetTotal) can then be used to display these values on the sheet (in the sheet's title block, for example) as text objects. Numbering schematic sheets in a project allows you to take control over the sheet designation and store them as parameters within the respective schematic documents. Using Compiled Sheet Annotation in Board Level Annotation.Schematic Sheet Numbering and Device Sheets.
